Energy

Energy consumption monitoring and power quality analysis with three-phase electrical measurement. Track voltage, current, and active/reactive/apparent power per phase, monitor power factor and harmonics (THD), manage demand peaks (kW/kVA), and perform time-of-use cost analysis with commercial segments — all through 8+ configurable Highcharts widget types and OPC UA integration.

Get Pricing Request Demo

Capabilities

Everything you need in one module

Three-Phase Electrical Measurement

Real-time monitoring of voltage, current, and active/reactive/apparent power per phase with per-phase breakdowns and system totals.

Power Factor & Harmonics

Track power factor across all phases with dedicated PF gauge widgets. Analyze Total Harmonic Distortion (THD) to identify power quality issues.

8+ Dashboard Widget Types

Configurable Highcharts dashboard with energy gauge, power triangle, PF gauge, three-phase diagrams, cost breakdown charts, and KPI cards.

Demand Tracking

Monitor kW, kVA, and peak demand in real time. Track demand patterns across shifts and time periods to optimize load distribution.

Time-of-Use Cost Analysis

Multi-tariff cost computation with commercial time-of-use segments. Analyze energy costs by peak, off-peak, and shoulder periods.

OPC UA Server-Side Monitor

Server-side energy monitor running at 3-second intervals with 14 OPC UA output variables per configuration for seamless SCADA integration.

Technical Details

Specifications & Requirements

Min. atvise® version	3.7.0
Communication	OPC UA (14 output nodes per config)
Monitor interval	3 seconds (server-side)
Widget types	8+ Highcharts (gauge, triangle, PF, 3-phase, cost, KPI)
Measurement	Three-phase V, I, P, Q, S per phase
Settings sections	7 (electrical, energy, PF, harmonics, demand, economics, shifts)
License model	Per configuration
Support tier	Standard + Premium available
